Characteristics of Zircons from Volcanic Ash-derived Tonsteins in Late Permian Coalfields of Eastern Yunnan, China
摘要: 本文就滇东晚二叠世含煤沉积中同沉积火山灰蚀变粘土岩夹矸和正常沉积粘土岩的锆石进行了统计学和形态学研究.该两种不同成因类型的粘土岩中锆石含量及形态面貌有显著区别.tonsteins中锆石形态参数统计规律因层位而异;同层位tonstein的锆石含量和形态参数在平面上呈有规律地变化.系统研究含煤建造剖面上各类岩石(包括tonsteins)中的锆石特征,能够用以确定物质来源、性质、成因以及以此为基本建立正常地层层序并精确对比层位,因而具有理论和实用意义.Abstract: The clayey coal-partings (tonsteins) of altered synsedimentary volcanic ash-fall origin are well developed in the Late- Permian coal-bearing formation of eastern Yunnan Province, an area of approximately 100, 000km~2. Because of their unique origin and stable lateral distribution over vast areas, great importance has been attached to the studies of tonsteins (i.e., unconventional claystones) . More than 20 layers (with a thickness in the range of 3-6 cm) of tonsteins were identified from the coal-bearing sequence 200-250 m thick. In order to distinguish tonsteins from the co-existing conventional claystones macroscopically and microscopically, to search for convergence of evidence on the origin of tonsteins from different approaches, to characteriae the individuality of tonsteins from different horizons, as well as to figure out the directions from which the source materials were derived, special techniques such as panned-concentrate separation, statistical and morphological analyses were performed on zircon minerals from claystones of two different origins and diageneses. The results demonstrate the fact that zircons of these two different origins are greatly different in their contents, morphological features and related parametric statistical patterns. The surficial features of these crystal solids also show apparent difference in origin. Tonsteins from the same area but different horizons are characterized by different zircon contents and different morphological paramieric statistical patterns. Tonsteins of the same horizon show close statistical associations in terms of zircon content and morphological parameters; there are continuous variations in statistical patterns in response to changes in lateral distribution of the same layer of tonstein. It was made possible to identify the different paths and directions in which the source materials of tonsteins (i.e., the volcanic ash-falls) or conventional claystones (i.e., the terrigenous clastic sediments) were derived and transported. Therefore, it is important to recognize the source materials and their nature and orgin by studying systematically the characteritics of zircons in various rocks (including tonsteins) along the profile of a coal-bearing formaiton, in order to provide the basic data as an aid in establishing the stratigraphic sequence, facilitating the more precise coal correlation in a mining area as well as improving the stratigraphic correlation on a reginal scale
 (1) 广东省地质局中心实验室编，1979，砂矿物图册，地质出版社，320页.
(9) Burger K., Zhou, Y. and Tang, D., 1990, Int. J.Coal`Geol., No.15: p.341-356.
(10) Dopita M. and Kralik J., 1977, Coal Tonsteins in Octrave-Karvina coil basin, CSSR. Octrava, p.213.
(11)' Diessel C.F.K., 1985, Tuffs and Tonsteinsin the coal Measures of New South Wales, Australia. X ICC, Sym- posium, No.8, p.197-210.
(12) 1"rancis E. H.，1985, Recent Ash-Fall A Guide:。Tonstein Distribution. X ICC, Symposium, No.:，p189-195, Madrid.
(13) lienderson P., 1984. Rare Earth Element G俞chemistry. Elsevier Science Publishers B.V.(田丰等译，1989，稀土元素地球化学，地质出版社，北京，p.284).
(14) :Pupin J.P., 1980, Contributions to Mineralogy and Petrology, V.73,' No.3', p.207-220.
(15) .Zhou Yiping, Ren Youliang and Bohor, B.F., 1982, Int. J. Coal Geol., No.2: p.49-77.
